d5d7fde30f
* updated color scaling to preserve hue at low brightness resulting in much better colors * replace NPBlg with NPB, moved brightness scaling to bus manager * improved gamma table calculation: fixed mismatch in inverting gamma table calculation: inversion should now be as good as it gets * code cleanup, fixed gamma being applied in unnecessary places Improvements to ABL handling: - removed strip level handling, ist now all done on bus level - limiter now respects pixel mapping - proper handling of white channel - improved current estimation - current is now always correctly reported to UI - minimal FPS impact if the ABL is not limiting but slighly higher impact for global ABL limit due to double-scaling - moved brightness scaling to BusDigital - created new header file colors.h to be able to access color functions in bus-manager. - updated colo_fade() with better video scaling to preserve hue's at low brightness - added IRAM_ATTR to color_fade (negligible speed impact when compared to inline and benefits other functions) - added IRAM_ATTR to color_blend as it is used a lot throughout the code, did not test speed impact but adding it to color_fade made it almost on-par with an inlined function Additional changes: - fixes for properly handling `scaledBri()` (by @blazoncek) - also use bit-shift instead of division in blending for ESP8266 - improvements for faster "softlight" calculation in blending - changed some variables to uint8_t to maybe let the compiler optimize better, uint8_t can be faster if read, store and set are all done in uint8_t, which is the case in the ones I changed - various minor code formatting changes
Welcome to my project WLED! ✨
A fast and feature-rich implementation of an ESP32 and ESP8266 webserver to control NeoPixel (WS2812B, WS2811, SK6812) LEDs or also SPI based chipsets like the WS2801 and APA102!
⚙️ Features
- WS2812FX library with more than 100 special effects
- FastLED noise effects and 50 palettes
- Modern UI with color, effect and segment controls
- Segments to set different effects and colors to user defined parts of the LED string
- Settings page - configuration via the network
- Access Point and station mode - automatic failsafe AP
- Up to 10 LED outputs per instance
- Support for RGBW strips
- Up to 250 user presets to save and load colors/effects easily, supports cycling through them.
- Presets can be used to automatically execute API calls
- Nightlight function (gradually dims down)
- Full OTA software updateability (HTTP + ArduinoOTA), password protectable
- Configurable analog clock (Cronixie, 7-segment and EleksTube IPS clock support via usermods)
- Configurable Auto Brightness limit for safe operation
- Filesystem-based config for easier backup of presets and settings
💡 Supported light control interfaces
- WLED app for Android and iOS
- JSON and HTTP request APIs
- MQTT
- E1.31, Art-Net, DDP and TPM2.net
- diyHue (Wled is supported by diyHue, including Hue Sync Entertainment under udp. Thanks to Gregory Mallios)
- Hyperion
- UDP realtime
- Alexa voice control (including dimming and color)
- Sync to Philips hue lights
- Adalight (PC ambilight via serial) and TPM2
- Sync color of multiple WLED devices (UDP notifier)
- Infrared remotes (24-key RGB, receiver required)
- Simple timers/schedules (time from NTP, timezones/DST supported)
📲 Quick start guide and documentation
See the documentation on our official site!
On this page you can find excellent tutorials and tools to help you get your new project up and running!
🖼️ User interface
💾 Compatible hardware
See here!
✌️ Other
Licensed under the EUPL v1.2 license
Credits here!
Join the Discord server to discuss everything about WLED!
Check out the WLED Discourse forum!
You can also send me mails to dev.aircoookie@gmail.com, but please, only do so if you want to talk to me privately.
If WLED really brightens up your day, you can
Disclaimer:
If you are prone to photosensitive epilepsy, we recommended you do not use this software.
If you still want to try, don't use strobe, lighting or noise modes or high effect speed settings.
As per the EUPL license, I assume no liability for any damage to you or any other person or equipment.
